General Specs |
| Color | Black |
| Color/Finish Name | Matte Black |
| Door Color | Matte Black |
| Handle Color | Matte Black |
| Trim Color | Matte Black |
| Total Capacity (cu. ft.) | 6.0 |
| Number of Oven(s) | Single |
| Fuel Type | Natural Gas |
| Door Panel Type | Glass Panel |
| Burner Type | Sealed |
| Range Type | Pro-Style |
| Number of Elements/Burners | 6 |
| Cooktop Surface Style | Burner Grate |
| Cooktop Surface | Stainless Steel |
| Oven Cleaning Method | Manual Clean |
| Oven Features | Automatic Convection Conversion, Broiler in Oven, Keep Warm, LED Display, Oven Light |
| Cooktop Features | Continuous Grate |
| Air Fry | No |
| Induction Cooking | No |
| Convection Cooking | Yes |
| Smart Compatible | No |
| Outdoor Approved | No |
| Downdraft Ventilation | No |
| Drawer Type | No Drawer |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 35.88 |
| Height (in.) | 40.25 |
| Depth (in.) | 28.75 |
| Depth w/Door Open 90 Degrees (in.) | 47.38 |
| Cut Out Depth (in.) | 24 |
| Cut Out Width (in.) | 36 |
| Cut Out Height (in.) | 36 |
| Shipping Width (in.) | 36 |
| Shipping Depth (in.) | 24 |
| Shipping Height (in.) | 36 |
| Product Weight (lbs.) | 195 |
| Manufacturer Warranty | 2 Year Parts & Labor |
| Commercial Use Approved | No |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Collection | A-Series |
| Series | A-series |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 15 |
Technical Details |
| Gas Line Regulator | 1 |
| Control Type | Oven Function Button + LED Panel Display |
| Plug Type | 3 Prongs |
| Cord Length | Cord Length |
Cooktop Performance |
| 1 – Front Left Burner (Single) | 12,000 BTU |
| 2 – Front Center Burner (Single) | 18,000 BTU |
| 3 – Front Right Burner (Single) | 12,000 BTU |
| 4 – Rear Left Burner (Single) | 9,000 BTU |
| 5 – Rear Center Burner (Single) | 12,000 BTU |
| 6 – Rear Right Burner (Single) | 9,000 BTU |
Oven Performance |
| Oven Features | Bake, Broil, Conv Bake/Roast, Pizza, Keep Warm |
| Bake Burner Power | 18,500 BTU |
| Broil Burner Power | 13,500 BTU |
| Convection | Convection Fan |
| Oven Light | 1 × 40W, Rear |
| Oven Rack Material | Chrome Plated |
| Baking Sheet Size | Fits up to 28" × 14" Sheet |
Additional Dimensions |
| Product Height (From Bottom to Top of Back Splash) | 37 1/4 – 40 1/4″ |
| Product Height (From Bottom to Top of Side Panel) | 36″ – 39″ |
| Product Depth (From Back Panel to Bullnose) | 26 7/8″ |
| Product Depth (From Back Panel to Control Board) | 26 1/4″ |
| Product Depth (From Back Panel to Side Panel Front) | 24″ |
| Adjustable Leg Sizes | 3" Max. |
| Oven Height | 18″ |
| Oven Width | 29.7″ |
| Oven Depth | 19.4″ |
Accessories Included |
| Broiler Pan | 1 |
| Bake Pan | 1 |
